E-Bike Key Specs
Battery
Bosch 750Wh
Display
Bosch Kiox 300
Motor
Bosch CX Gen 4
Range
30-160 miles
Specifications
General Bike Specifications
Frame Aluminium, through axle M12 (1.00) x 148mm, disc brake Post Mount
Forks SR Mobie 25 LOR Lockout, steel spring, alum shaft 1 1/8" - 1 1/2„ tapered, thru-axle, Travel: 100mm
Brakes Shimano MT410, aluminium, 180mm
Shifters Shimano Cues U6000, rapidfire
Rear Mech Shimano Cues U6000, 11-speed
Cassette Shimano Cues LG400, 11-50 teeth
Chain Shimano Cues LG500
Wheelset Rodi Tryp 30, eyed, double-walled rim, aluminium
Tyres Schwalbe Al Grounder Performance, 60-584
Handlebars Haibike Components TheBar ++ 740mm
Stem Haibike Components TheStem ++, A-head, Bar bore: 31.8mm, 12 ̊
Headset A-Head Tapered
Seatpost Patent, 34.9mm, aluminium
Saddle XLC Trekking
Weight 27 kg
Electric Bike Specifications
Battery Bosch PowerTube 750Wh
Display Bosch Kiox 300 + LED Remote
Motor Bosch Performance CX Smart System, 250W, 85Nm, 25km/h
Range 30 - 160 miles of power assisted range, depending on terrain
