E-Bike Key Specs
Battery
Yamaha 630Wh
Display
Display C
Motor
Yamaha PW ST
Range
30-140 miles
Specifications
General Bike Specifications
Frame Alu 6061, Hydro Formed with Internal Cable Routing
Forks SR Suntour Mobie A32, 75mm
Brakes Shimano MT401 Hydraulic Disc Brakes, 180mm
Shifters Shimano Deore M5100, 11-Speed Triggers
Rear Mech Shimano Deore M5100, 11-Speed
Cassette Shimano M5100, 11-Speed 11-51t
Chain KMC e11s 11-Speed
Wheelset Schurmann 25mm Alloy Rims on Shimano Hubs
Tyres WTB Groove-E 27.5 x 2.40"
Handlebars XLC TopFlat 720mm
Stem XLC Alloy 31.8mm
Headset A-Head, Alloy
Seatpost XLC, Alloy, 31.6mm
Saddle Selle Royal Wave Comfort
Weight 27.4 kg
Electric Bike Specifications
Battery Yamaha Lithium Ionen 36 Volt, 630 Wh, with BMS Management
Display Yamaha Multi Switch, 2.8" TFT multi-functional LCD display with walk assistance
Motor Yamaha PW-ST Crank Drive 36V 250 Watt. 50 - 280% Assist, 70Nm
Range 30 - 140 miles of power assisted range, depending on terrain
